TLC SILICA GEL 60 W F254S

General description

25 Aluminium sheets 20 x 20 cm

Our classical silica TLC plates are based on a combination of our proven silica gel 60 and the addition of a unique polymeric binder resulting in a very adherent and hard surface that will not crack or blister and even allow writing with a pensil on the surface without risk to damage the layer.

Linkage

Replaces: 16484-1; 16484

Analysis Note

Specific surface area (according to BET; 5-Pt. measurement): 480 - 540 m²/g
d 50 (laser diffraction, size distribution): 9.7 - 11.7 µm
Layer thickness: 120 - 160 µm
Deviation of layer thickness per plate: ≤ 40 µm
Chromatographic testing:
colour test
hRf-values
- Benzene-azo-a-naphthylamine:
40 - 55
- Brillant red B: 60 - 75
- Erio green B: 75 - 90
separation number (colourtest, lipophile): ≥ 9.0
Typical value determined on a sheet
Eluent: Ethylmethylketone/ 1-propanol/ glacial acetic acid/ water (40/40/5/20 v/v/v/v)

material: aluminum support, silica gel 60 matrix. Quality Level: 100. feature: binder Organic Polymer, fluorescent indicator. packaging: pkg of 25 . sheets. technique(s): thin layer chromatography (TLC): suitable. layer thickness: 200 . μ. m . sheet L × W: 20 . cm × 20 . cm . particle size: 10-12 . μ. m. pore size: 60 . Ã… medium pore diameter. storage temp.: 2-30°C. Storage Class Code: 10-13 - German Storage Class 10 to 13.
