MILLEX-GS SYRINGE FILTER UNIT 0.22¡UM MIXED CELLULOSE ESTERS 25¡MM WITH VENTED INLET ETHYLENE OXIDE STERILIZED

General description

Vented Millex^®-GS filter units are syringe filters for sterilization of low volume aqueous solutions where venting is desired.

Specificity

Materials

Filter membrane: Hydrophilic MF-Millipore^® mixed cellulose esters (MCE), type GS, pore size 0.22 μm
Vent membrane: Hydrophobic polytetrafluoroethylene (PTFE), pore size 0.03 μm
Housing: Polyvinyl chloride (PVC)

Dimensions

Inlet to outlet: 27 mm (1.06 in.)
Diameter: 29 mm (1.14 in.)
Filtration area: 4 cm² (0.62 in²)
Temperature limit: 45 °C (113 °F)
Pressure limit at 21 °C: 5.2 bar (75 psi) inlet and differential
Filtration volume: 1–100 mL
Hold-up volume: ≤ 0.1 mL after air purge
Sterilization method: Ethylene oxide gas
Connections: Female Luer-Lok^® inlet, male Luer-slip outlet
Flow rate at 0.7 bar (10 psi), 21 °C: ≥ 30 mL/min
Bubble point (water): ≥ 50 psi

Color: clear inlet, blue outlet

Application

Syringe filter for vented sterile filtration of low volume aqueous solutions

Features and Benefits

• For research use only (RUO)
• Single use only
• Vented inlet to prevent air locking
• Non-pyrogenic and non-toxic

Legal Information

Luer-Lok is a registered trademark of Becton-Dickinson & Co.

Millex is a registered trademark of Merck KGaA, Darmstadt, Germany

Millipore is a registered trademark of Merck KGaA, Darmstadt, Germany
