Gold coated slides (C007B-185890)

DescriptionVis-IR extinction-peak wavelength: 580-620 nm.Vis-IR extinction-peak OD: 0.6-0.9Vis-IR extinction-peak OD-average: 0.6-0.8.Vis-IR extinction-peak OD-intraslide CV: <15%.Fluorescence enhancement: >50 times at 800 nm.Our gold coated slides contain ~100 nm thick film of nanostructured plasmonic gold particles and find applications as fluorescence enhancing substrates for many fluorophores emitting in the 600-1700 nm range, including Cy5, Alexa Fluor®647, IRDye®800 and others. These gold substrates can also be used to enhance Raman scattering signals. Using these slides an enhancement in Raman signal up to 100-fold can be achieved at ~800 nm emission channel. A 5-10 fold increase in scattering can be obtained in the visible light range. These slides are also capable of enhancing surface Raman scattering signals up to 107fold.

Specifications and Purity: layer thickness 100nm , gold, size 75mm×25mm×1mm

Related Documents: https://aladdin-for-icloud-store.oss-cn-hangzhou.aliyuncs.com/aladdinsci/pdp/sds/1/G476180-SCI_64207a2ff9a440d08dffb2091c1422d9.pdf
