Medical vacuum systems

Increased sensitivity and versatility over other models, mercury requirement is reduced to 20-30cc. A control point within 1mm Hg can be fine-tuned by adjusting the height of the pump-out tubulation.

Double jacketed with standard taper inner and outer joint at bottom and top.

With spiral condensing tube having both inlet and outlet connections at top, on same side. With standard taper joints. Length between joints is approximately 80-90 mm longer than the stated coil length.

Spiral reflux condenser with inlet and outlet hose barbs located on the same side at the top of the condenser body for easy hose connections. These condensers are available in multiple lengths which allow for greater surface area dependant on the

Vacuum trap assembly with o-ring flange connection. This design has flexibility and ease of assembly-disassembly for cleaning. Comes with Viton o-ring and stainless steel pinch clamp.

High efficiency coil condenser especially suited for vacuum applications. Coil length is 70mm.

Consists of Body with Ace-Thred, adjustable Inner Tube and Nylon Bushing with FETFE O-Ring. Available with optional threaded tubing adapters (-75,-78), or modified with #15 Ace-Threds on inlet/outlet for use with PTFE Ace-Safe connectors to allow

Consists of Body with Ace-Thred, adjustable Inner Tube and Nylon Bushing with FETFE O-Ring. Available with optional threaded tubing adapters (-75,-78), or modified with #15 Ace-Threds on inlet/outlet for use with PTFE Ace-Safe connectors to allow

Threaded vacuum release valve with fingertip control for opening systems to the atmosphere. Plunger stem made of PTFE with single O-Ring of FETFE.

Thomas No. 1165A11 14/20 vacuum adapter, 30mm stem below the joint. Thomas No. 1165A12 14/20 vacuum adapter, 175mm stem below the joint. Thomas No. 1165A13 19/22 vacuum adapter, 30mm stem below the joint.

Hign vacuum manifold systems feature Easy Action PTFE stopcock valves providing for greaseless operation. Double-tube codes -50 & -54 feature Ace-Threds and 8mm OD tube-end ports.

Available with standard taper or spherical joint. Stem below joint is 250mm. Hose connection is size C.
